god daaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaamn
i fucked up and tried to run 4/0 4/0 2/0 aluminum through a 2" lb.
i fucked up and tried to run 4/0 4/0 2/0 aluminum through a 2" lb.
TrollfaceDeux
Pronouns: zie/zhem/zer
- 19,577
- 3,743
ZyyzYzzy
RIP USA
- 25,295
- 48,789
Live big and get parma. Also, the best breakfast in the world is to fry up some of that shit to scramble with eggs. I'm so glad my family is guiddodific.
Erronius
<WoW Guild Officer>
- 17,229
- 44,563
I thought you got a quote? Are you just doing it yourself instead?
You can get aluminum 4/0 4/0 2/0 through 2" LBs, but one direction is much easier to come from and it also depends on what kind of cable you're using. If you're trying to send through a fully sheathed cable with those 3-4 conductors inside (depending on what you're using) then that will be a nightmare (especially stuff like SEU/SER). I'd use something like THWN/XHHW or something similar that don't come in a sheathing and when you go through LBs, you can "unbraid" the cables and then pass individual conductors through the LB if you are having a hard time. Also what you're running as your service entry cable affects conduit fill; IIRC stuff like SER is calculated differently because from a cubic fill perspective it's just one much larger sheathed cable instead of having 3-4 individual conductors w/o sheathing that are probably sized for conduit fill as individual conductors.
Also don't forget to use antioxidant goop on your connections if you're using aluminum.
I got two quotes for 1600 but they took too Damn long so I went ahead on my own.
The 4/0 are all separate I actually had them in there but the Damn lb popped off and I couldn't get it back on without pulling them. If you say it's possible I'm going to glue them and I'll just be mega fucked if it doesn't work.
The 4/0 are all separate I actually had them in there but the Damn lb popped off and I couldn't get it back on without pulling them. If you say it's possible I'm going to glue them and I'll just be mega fucked if it doesn't work.
