What a weird issue, but i cant complain myself - try using extenders and swapping to another fan header - similarly if youre using a fan hub use a 3 in 1 instead and route them differently.
Desktop Computers
- Thread starter brekk
- Start date
-
Guest, did you like the last podcast notification?? Well here's the second one, and for the third podcast! Yep. This Thursday 8-8-24 at 7pm Central
Go here to check out his podcast thread for info on topics and links!Go into the FoH discord and find the Happy Time Fun Hour channel and give it a listen!
What a weird issue, but i cant complain myself - try using extenders and swapping to another fan header - similarly if youre using a fan hub use a 3 in 1 instead and route them differently.
Denamian
Night Janitor
- 7,367
- 19,420
GN just posted a review of a Starforge prebuilt a few days ago. They were overall pretty happy with it.
- 1
Tmac
Adventurer
- 9,842
- 16,737
Xexx
Vyemm Raider
- 7,644
- 1,750
Tmac
Adventurer
- 9,842
- 16,737
So a new one of these?
[edit] I noticed that the top plug wasn't seated properly and fixed it, but it didn't change anything.
Brikker
Trump's Staff
- 6,242
- 4,721
Fuck it, ordered a Starforge PC with the 7800x3d and a 20gb Radeon 7900 xt. Haven't made a purchase for that much for myself in awhile. Early birthday present! No microcenter anywhere near me or I'd have gone that route.
Definitely gonna be a big boost from my 2070 super and 9900k.
Definitely gonna be a big boost from my 2070 super and 9900k.
- 2
Jovec
?
- 774
- 312
Not sure what is actually going on, but I have questions...
1) What are the actual temps when gaming and benching on the 4090? In terms of heat generation, that is temp independant and the card is 450w stock and can hit 600w.
1A) Which temps are you looking at? Modern AMD and NV cards report both the GPU temp and GPU hotspot/junction temp and these can vary by 10-20C.
2) What scores/FPS does the card get? Compare to similar setups to see if the 4090 is throttling.
3) Fan Control doesn't need/use a fan header to control GPU fans, but rather the GPU temp as reported by software. It's possible that running multiple monitoring apps my F that up
4) I've had GPUs that had a fan header, but that was used to power a case fan based on GPU temps. It's not an input so don't connect a header from the mobo to the GPU that way.
5) In that HwInfo64 SS, the GPU info will be at or near the bottom. The section shown is the SS is the mobo info that HwInfo warns might be buggy due to the EC Asus uses (Though I've never known it to be a problem)
6) Make sure the GPU power cable is fully plugged in, from the card, to adpaters (if any), to PSU. It shouldn't be possible unless you really force it, but if you are using a 12v Highpower connector to multiple PCIe 8 pin adapter, make sure you are using the PCIe 8 pin cables and not CPU 8 pin.
7) GPU fans are always loud over ~50% PWM anyway...so you need to confirm if it is a temp problem or an expectation problem.*
8) It's possible the card's cooler has a bad mount that makes poor contact between the GPU die and heatsink coldplate, and that mount has gotten worse (gap too large with poor paste contact) over time due to thermal cycling. I would confirm high temps / throttling before I went to the trouble of repasting.
9) Consider warranty service before disassembling.
*The first GPU AIB that ships GPUs with simple 120x25mm fan mounts as stock will print money.
1) What are the actual temps when gaming and benching on the 4090? In terms of heat generation, that is temp independant and the card is 450w stock and can hit 600w.
1A) Which temps are you looking at? Modern AMD and NV cards report both the GPU temp and GPU hotspot/junction temp and these can vary by 10-20C.
2) What scores/FPS does the card get? Compare to similar setups to see if the 4090 is throttling.
3) Fan Control doesn't need/use a fan header to control GPU fans, but rather the GPU temp as reported by software. It's possible that running multiple monitoring apps my F that up
4) I've had GPUs that had a fan header, but that was used to power a case fan based on GPU temps. It's not an input so don't connect a header from the mobo to the GPU that way.
5) In that HwInfo64 SS, the GPU info will be at or near the bottom. The section shown is the SS is the mobo info that HwInfo warns might be buggy due to the EC Asus uses (Though I've never known it to be a problem)
6) Make sure the GPU power cable is fully plugged in, from the card, to adpaters (if any), to PSU. It shouldn't be possible unless you really force it, but if you are using a 12v Highpower connector to multiple PCIe 8 pin adapter, make sure you are using the PCIe 8 pin cables and not CPU 8 pin.
7) GPU fans are always loud over ~50% PWM anyway...so you need to confirm if it is a temp problem or an expectation problem.*
8) It's possible the card's cooler has a bad mount that makes poor contact between the GPU die and heatsink coldplate, and that mount has gotten worse (gap too large with poor paste contact) over time due to thermal cycling. I would confirm high temps / throttling before I went to the trouble of repasting.
9) Consider warranty service before disassembling.
*The first GPU AIB that ships GPUs with simple 120x25mm fan mounts as stock will print money.
Last edited:
Tmac
Adventurer
- 9,842
- 16,737
Jovec
?
- 774
- 312
Take at look at Windows Task Manager (expand/show details if needed) and look for your GPU down the left column. Highlight and Windows should show temps for NV cards.
Uninstall Nvidia drivers and run a driver cleaner. Reinstall drivers and select option for a fresh install / settings reset (however they word it) and try again. If it still persists uninstall all apps that monitor stuff and try again (hwinfo, fan control, msi afterburner/etc...
Edit: If you have a spare SSD/NVMe and USB stick, I'd even consider downloading Windows and making an installable USB (windows media creation utility), then installing a fresh copy of Windows and just the NV drivers and see what happens. If you aren't getting GPU temps after that, I'd suspect a problem with Temp sensor/controller on the card.
Last edited:
Lanx
<Prior Amod>
- 63,378
- 140,534
is it the newest ver of hwinfo?
even task manager now shows gpu and temp, goto task manager->performance-> gpu
Tmac
Adventurer
- 9,842
- 16,737
A proper roar at 35C. Once I turn off Diablo IV it drops to 31C and sounds like a loud PC. Wait a little while and it gets less lout around 29C.
Although even at 29C it has something high pitched going on. I'm dropping the GPU to 1.5% fan speed at 28C and it's still loud. Got dang.
There are some other fans in the box that stay at 2200 RPM's tho. Which I think are my two radiator fans.
Actually. I think the main culprit might be the Corsair radiator fans :O
Last edited:
Lanx
<Prior Amod>
- 63,378
- 140,534
and what is controlling your fan curves?
it might be easier to just download msi afterburner and let it just control your fan, no overclocking
Tmac
Adventurer
- 9,842
- 16,737
Currently using Fan Control for GPU since none of my other fans show up.
I think the issue is the CORSAIR H100I ELITE CPLXXT 240 BK fans tho. Loud AF and I can't figure out how to slow them down.
Lanx
<Prior Amod>
- 63,378
- 140,534
i thought you said your main issue was the gpu is loud
and in default fan curve, gpu fans don't even spin until they hit 50c, if youre already spinning at idle 29c, you got something taking over your gpu fans
i know it sounds freaky, but just the sheer mass of the gpu heatsink is enough to keep it at 50c w/ fans at idle, if youre spinning at 35c something has taken control.
are you also using corsair icue software?
- 1
Fucker
Log Wizard
- 12,296
- 27,661
Tmac
Adventurer
- 9,842
- 16,737
Fucker
Log Wizard
- 12,296
- 27,661
Tmac
Adventurer
- 9,842
- 16,737
Well, when I first built it the fans weren't an issue, which was back in May of last year.
But, I'd guess atleast ~9 months. It seemed to only start bothering me about a month ago though.
